4.2m S PP spunbond non woven machine

Payment Type:	L/C,T/T
Incoterm:	FOB,CFR,CIF
Min. Order:	1 Set/Sets
Delivery Time:	90 Days

Contact Now

Basic Info

Model No.: YF-4200S

Machine Model: S

Product Width: 4.2m

Additional Info

Packaging: Wooden box, carton

Brand: AL(Aolong)

Transportation: Ocean,Land

Place of Origin: Zhejiang, China (Mainland)

Port: Ningbo,Shanghai

Product Description

Product Description

The equipment produces nonwoven fabric with PP, adopts the technology of air drawing into web forming machine by negative pressure to make the PP spunbond nonwoven fabric, the product is featured by uniform cover, great intensity, good breathable and good feeling. It's widely used for medical.protective products.household.hotel accessories.beauty care disposable product.agricultural cover.clothes package and architecture.

1)The whole line is well-structured and easy operating.
2)Control elements are of well-know made,high performance and reliable technology.
3)The whole line are controlled by PLC and operated with touch-screen.
4)The allocation of the main frame and auxiliary equipment can be specially designed and adjusted according to customer's requirement.
5)No waste, No pollution.

Detailed Images

Q20170417143250pp spunbond non woven fabric line

Name: Spinning box

Name: Spinning Box
Orifice number:11019 for 1.6m,
17651 for 3.2m
Orifice diameter:φ0.45mm
L/D=4:1
Max temperature:300℃

Name: Fliter
Type:hydraulic or candle filter
Filtration precision:45μm-60μm
Filtration area:2.5㎡ for 1.6m
3.5㎡ for 3.2m
Max pressure:12Mpa for 1.6m
16Mpa for 3.2m
Heat source:heat-transfer oil circular heating

Name: Winding machine

Max winding diameter:φ1200mm
Speed:10-150m/min for S type,
10-300m/min for SS/SMS type
Motor:5.5-7.5KW

Name: Electrical cabinet
Fuction:Controlled by PLC with Siemens brand, touch
screen,frequency converter,main DC motors.
Adjuster:RKC F900/PT100,Japan,Velometer:Eurothaim SSD 590/591,English Electronic element: CHINT, Yaskawa/Fuji/Parker/ABB or Siemens.
